Water Extraction
11 L/H
Air Circulation
~4,500 M³/H
Patent Protected
The DG-3 50Hz is a compact dehumidifier, designed to provide effective and efficient dehumidification, while fitting in any greenhouse.
The new model utilizes the latest technologies and innovative engineering to maximize dehumidification capacity and air circulation, while emphasizing minimal electricity requirements. The unit includes a detached electric cabinet and 8-meter cable for improved accessibility.
DryGair dehumidifiers are designed by a team of agronomists and climate engineers to address humidity, specifically in cultivation settings. Our team also assists every single grower in choosing the best solution for their unique facility and environment. DryGair is manufactured to uphold the highest standard, and comply with GMP regulations.
DG-3 Features
360° air dispersal for climate uniformity.
Units designed for indoor use are engineered for optimal performance under common grow room conditions of 27°C and 60% relative humidity.
DG-3 Photos
Technical Details
| Depth | 1,400 mm |
| Width | 1,010 mm, lower part can be shorter |
| Height | 910 mm, 1,362 mm with air distribution module (exact height can be adjusted) |
| Weight | ~300 kg |
| Depth Remote Electrical | 250 mm |
| Width Remote Electrical | 500 mm |
| Height Remote Electrical | 700 mm |
| Weight Remote Electrical | ~24 kg |
| Operating Temperature | 10°C – 35°C |
| Water Condensation | 11 L/h @18°C ,80% RH |
| Water Extraction Efficiency | 4.8 L/kWh |
| Air Flow | ~4,500 m³/h |
| Electricity Consumption | 2.3 kW |
| Electricity Requirements | 3 phase, 400V, 50 Hz I(Oper. max)= 14 Amp |
| Type of Refrigerant | R513A (GWP 573) |
Technical Sketches
Technical Videos
How to reset your DryGair unit
How to install 3 phase DryGair units
Available Add-Ons
Defrost Coil
The electric defrosting system, designed for the DG-12 and DG-3, tackles this problem head-on by preventing ice formation, ensuring dependable dehumidification even at temperatures as low as 6°C (43 °F). This innovation allows for precise humidity control across a broader temperature range, no matter the conditions. The result? Healthier plants and better yields all year long.
Please note: the defrost coil is available only by pre-order and increases the unit height by approximately 5–10 cm. (2–4 in.).
Castors (Wheels)
Add castors to DryGair units for easy transport in the growing facility. The wheels add ~9 cm (~3.5″) to the unit’s height.
Protective Wire Net
This robust metal cover protects the outer coils on both sides of the machine from physical damage. The cover is screwed around the coils on both sides of the unit.
Resistance To Chemicals And Sulphur
This coating treatment will protect the coils, inner copper components and welded parts from corrosion and will provide resistance to various harmful agents and particles. Contact us for the full list of chemicals.
Side Canopy
Unidirectional hoods For units positioned on the side of growing facilities. This side canopy will direct the unit’s airflow in one or two directions depending on the needs of the facility. Sizes: Height 570 mm (22.4”), Depth 630 mm (24.8”), Width 570 mm (22.4”)
