DG-12 50Hz Standard

Efficient Water Extraction, Large Coverage, Patented Air Circulation

Drygair Water Extraction icon

Water Extraction

48 L/H

Drygair Air Circulation icon

Air Circulation

~23,000 M³/H

Patent Protected

Patent Protected

DG-12 50Hz Standard is DryGair’s award winning flagship unit. Condenses up to 48 liters of water per hour, using less than 1 kWh per ~4 liters. It is the perfect balance of efficient, large-scale dehumidification with plug & play ease of use.

DryGair dehumidifiers are designed by a team of agronomists and climate engineers to address humidity, specifically in cultivation settings. Our team also assists every single grower in choosing the best solution for their unique facility and environment. DryGair is manufactured to uphold the highest standard, and comply with GMP regulations. DG-12 comes in 2 variations (50 Hz and 60 Hz), in order to accommodate growers worldwide.

The DG-12 50Hz series includes: DG-12 50Hz Standard, DG-12 50Hz Split, DG-12 50Hz Heating & Cooling, DG-12 50Hz Heating & Cooling Split

DG-12 Series Features

DG-12 Series Photos

Technical Details

Depth 933 mm
Width 2,570 mm
Height 2,270 mm, 2,770 mm with air distribution module (exact height can be adjusted)
Weight ~920 kg
Operating Temperature 10°C – 40°C
Water Condensation 48 L/h @18°C ,80% RH
Air Flow ~23,000 m³/h
Electricity Consumption 12 kW
Electricity Requirements 3 phase, 400V, 50 Hz I(Oper. max) = 44 Amp
Type of Refrigerant R513A or R134A

Technical Sketches

Technical Videos

How to install 3 phase DryGair units
How to reset your DryGair unit

Available Add-Ons

Defrost Coil

The electric defrosting system, designed for the DG-12 and DG-3, tackles this problem head-on by preventing ice formation, ensuring dependable dehumidification even at temperatures as low as 6°C (43 °F). This innovation allows for precise humidity control across a broader temperature range, no matter the conditions. The result? Healthier plants and better yields all year long.
Please note: the defrost coil is available only by pre-order and increases the unit height by approximately 5–10 cm. (2–4 in.).

Smart DG Controller

An advanced interface that allows growers to monitor and control their DryGair units both remotely and locally.

Castors (Wheels)

Add castors to DryGair units for easy transport in the growing facility. The wheels add ~9 cm (~3.5″) to the unit’s height.

Protective Wire Net

This robust metal cover protects the outer coils on both sides of the machine from physical damage. The cover is screwed around the coils on both sides of the unit.

Resistance To Chemicals And Sulphur

This coating treatment will protect the coils, inner copper components and welded parts from corrosion and will provide resistance to various harmful agents and particles. Contact us for the full list of chemicals.

Side Canopy

Unidirectional hoods For units positioned on the side of growing facilities. This side canopy will direct the unit’s airflow in one or two directions depending on the needs of the facility. Sizes: Height 850 mm (33.5″), Depth  910 mm (36″), Width 910 mm (36″)

Status Signal Light

External light to signal unit activity, stand-by mode, and errors.

Water Meter

DryGair Smart DG units can be installed with a high-end water meter to enable measurement of the amount of water extracted by the unit. It is attached to the drainage pipe at the bottom part of the unit and measures the amount of water by pulses of 100 ml. (3.4 oz.) The meter is directly connected to the main controller and has a battery that will last for 10 years. By Arad group.
