DG-6 North America Split

Easy Integration, Efficient Water Extraction, Large Coverage, Patented Air Circulation

HomeDEHUMIDIFIERSDG-6 North America Split
DG-6 split
Drygair Water Extraction icon

Water Extraction

6 G/H

Drygair Air Circulation icon

Air Circulation

~7000 CFM

Patent Protected

Patent Protected

DG-6 is designed for smaller commercial greenhouses, and shares the high efficiency of the larger DG-12. It features the same unique, slim design and air distribution module.

Space in any growing facility is precious, and growers should be able to maximize their use of it. Every meter counts. The DG-6 split upper and lower parts can be positioned according to the greenhouse’s specific limitations. Easy placement in the center or side of the greenhouse, along the aisles, on the ground or hung. The unit comes equipped with the SmartDG system to monitor and control DryGair remotely. *Subscription to the SmartDG service is sold separately.

DryGair dehumidifiers are designed by a team of agronomists and climate engineers to address humidity, specifically in cultivation settings. Our team also assists every single grower in choosing the best solution for their unique facility and environment. DryGair is manufactured to uphold the highest standard, and comply with GMP regulations. DG-6 comes in 2 variations (50 Hz and 60 Hz), in order to accommodate growers worldwide.

The DG-6 series includes: DG-6 North America Standard, DG-6 North America Split, DG-6 North America Heating & Cooling, DG-6 North America Heating & Cooling Split

DG-6 Series Features

DG-6 Series Photos

  • DG-6 dehumidifier
  • dg-12 dehumidifier flower greenhouse
  • DG-6 dehumidifier

Technical Details

Depth Upper Part3’-8”
Width Upper Part7′-7¼”
Height Upper Part
3′-8 ¾”, 5′-4¼” with air distribution module (exact height can be adjusted)
Weight Upper Part~600 lbs
Depth Lower Part2’-8¼”
Width Lower Part6’-2¾”
Height Lower Part
3’-1”
Weight Lower Part~600 lbs
Max. Distance Between Parts13.5’
Optimal °F Range50°F – 80°F
Water Condensation6 g/h @64°F ,80% RH
Air Flow~7,000 CFM
Electricity Consumption6 kW
Electricity Requirements3 phase, 460V, 60 Hz/ I(Oper. max) = 16 Amp
3 phase, 208V, 60 Hz/ I(Oper. max) = 30 Amp
Type of RefrigerantR507

Technical Sketches

Technical Videos

How to install 3 phase DryGair units
How to reset your DryGair unit

Smart DG

Smart DG by DryGair

An interface that lets growers monitor and control their DryGair units remotely and locally. The Smart DG system includes an interactive platform that collects data and provides full control over DryGair units. The system includes a smart sensor and physical offline interface, integrated into the dehumidifier. It also provides a remote interface which is accessible through any web browser, on any device (PC, smartphone, etc.).

READ MORE

Available Add-Ons

Air Filter

The air filters cover the coils on both sides of the unit and protect it from dust and small debris particles. They come with a magnetic frame for easy attachment and detachment for cleaning, and do not impede airflow into the machine.

Castors (Wheels)

Add castors to DryGair units for easy transport in the growing facility. The wheels add ~9 cm (~3.5″) to the unit’s height.

Heating & Cooling Kit

Heating and cooling kits can be added to DG-12 and DG-6 (Standard or Split models), to provide additional heating and cooling functions. The heating and cooling system requires an external hot or cold water source. Specifications are calculated by the DryGair team on a case-by-case basis.

Protective Wire Net

This robust metal cover protects the outer coils on both sides of the machine from physical damage. The cover is screwed around the coils on both sides of the unit.

Resistance To Chemicals And Sulphur

This coating treatment will protect the coils, inner copper components and welded parts from corrosion and will provide resistance to various harmful agents and particles. Contact us for the full list of chemicals.

Side Canopy

Unidirectional hoods For units positioned on the side of growing facilities. This side canopy will direct the unit’s airflow in one or two directions depending on the needs of the facility. Sizes: Height 850 mm (33.5″), Depth  910 mm (36″), Width 910 mm (36″)

Silencing Component

Noise reducing add-on suppresses noise from compressor operation.

Status Signal Light

External light to signal unit activity, stand-by mode, and errors.

Water Meter

DryGair Smart DG units can be installed with a high-end water meter to enable measurement of the amount of water extracted by the unit. It is attached to the drainage pipe at the bottom part of the unit and measures the amount of water by pulses of 100 ml. (3.4 oz.) The meter is directly connected to the main controller and has a battery that will last for 10 years. By Arad group.

DG-6 Series Downloads

Download User Manual
Download Technical Catalog
